Atenix's product

ATX-K075

MVB Ethernet gateway
Product Name ATX-K075
Form Factor 3U 4TE
Dimension Front panel: 20.32 mm x  128.4 mm – Depth 212 mm
Rapid description MVB <-> Ethernet gateway
Processor 32 bit MCF5329 ColdFire Core V3 @ 240 MHZ
Internal Ports 32 MB Sdram memory – 32 MB Flash memory – 32 KB Sram on processor – RTC device
External Ports 1x Ethernet interface @ 10Base-T and 100Base-TX – 2x EMD isolated MVB bus interfaces compliant to the IEC 61375 TCN standard
Envinronment T3 class
IP Grade Not Applicable
Power Supply +5 Vdc
Basic Software MQX RTOS 2.5 – Library TCP/IP – Library TCN
Compliance EN 50155:2007
Safety SIL 0
