Atenix's product

ATX-K280

Switching Power Supply
Product Name ATX-K280-ALI-01-0 – ATX-K280-ALI-02-0
Form Factor 3U 11TE
Dimension Frontal panel 55.6 mm x 128.4 mm – Depth 162 mm
Rapid description Switching Power Supply
Processor Not Applicable
Envinronment TX class
IP Grade Not Applicable
Power Supply Input Extended range: +16.8 Vdc ÷ +137.5 Vdc
Power Supply Outputs Type 01:   Vout1 = Nominal +5.1 Vdc/5A, Vout2 = Nominal +12.6 Vdc/2A, Vout3 = Nominal +24 Vdc/0.5A – 60W                                      Type 02: Vout = Nominal +24 Vdc/2.5 A – 60W
Basic Software Not Applicable
Compliance EN 50155:2007
Safety SIL 0
